Thermal Module
|
Habrok PRO HQ50L
|
Habrok PRO HQ50LN
|
Thermal Sensor
|
640 x 512, 12 µm
|
640 x 512, 12 µm
|
NETD
|
Less than 15 mK
|
Objective Lens
|
50 mm / F1.0
|
Field of View
|
8,8° × 5,3° / 15,4 m × 9,3 m
|
Detection Range
|
2600 m
|
Optical Module
|
Resolution
|
3840 x 2160
|
IR Illuminator Wavelenght
|
850nm
|
940nm
|
Field of View
|
7,3°× 4,1° / 12,6 m × 7,2 m
|
Smart IR
|
Yes
|
Viewing Range at Nigth
|
850nm = 400 m / 940nm = 350 m
|
Laser Rangefinder
|
1000m measuring distance
|
Display
|
Display
|
0.49 inch, OLED, 1920x1080
|
Magnification
|
Thermal: 4,3x to 25,8x, Optical: 5,5x to 22,0x
|
Image mode
|
Thermal: Black Hot, White Hot, Red Hot, Fusion
|
Optical: Day, Night, Auto
|
Zoom Pro
|
Yes
|
Image Pro 2.0
|
Yes
|
Record Video
|
Yes
|
Audio Recording
|
Yes
|
Storage
|
64 GB Built-in
|
GPS
|
Yes
|
Digital Magnetic Compass
|
Yes
|
Power Supply
|
Battery Type
|
Replaceable and Rechargeable Li-ion Battery
|
Battery Operation Time
|
=7 h (20°C, with hotspot off)
|
General
|
Protection Level
|
IP67
|
Work Temperature
|
-30 ~ 55?
|
Dimension
|
142,9 mm × 79,7 mm × 230,5 mm
|
Weight (w/o batteries)
|
975 gram with batteries
|
